Salice Wind Door Lifting System

Catch device to be used to increase the magnetic holding strength. It must always be used together with the salice DPM series release devices. ø 10 mm, 40 mm length.

Features
• The weight of the door must also be considered when selecting the correct lift system. Please refer to the charts system selection by weight and door dimension.
• * The Wind lift is supplied with an angle reduction clip installed, reducing the opening angle to 85 degrees.
• The reduction clip may be removed to achieve an opening angle of 94 degrees if the "K" boring distance on the door is 5mm or less.
• *Opening angle of 85 degrees.
• Maximum door thickness: 28mm (1-1/8").
• Minimum door thickness: 16mm (5/8").
• Top overlay possibility: From 16mm to 20mm.
• Edge bore distance on the door: 3.0mm to 7.0mm.
• Depth adjustment: -1.0mm, +3.0mm.
• Side adjustment: +2.0mm, -2.0mm.
• Height adjustment: +2.0mm, -2.0mm.
• Available with soft close or Push self open features.
